used in coal washery slurry pump guard plate ceramic rubber lining pipeline repairing and protecting
One of Taian coal washery slurry pump impeller diameter is 750cm,outlet diameter is 250mm,the weight of guard jacket is 0.5 ton,
the guard jacket is wearing perforated.
The condition before repairing: almost scrapping.
Material selection:
BD7042 slurry pump epoxy repair compound super abrasion wear resistant coating,BD426T special undercoat.
Construction tools:
Angle grinder,wire brush,grinding wheel,plaster knife,plastic knife,rubber hammer,special rounding tools,hair brush,
electronic scale,iodine-tungsten lamp.
Auxiliary materials: cleaning agent,duster cloth,gloves.
Construction technology of BD7042 super wear abrasion resistant slurry pump repair epoxy coatings:
1.Clean up and polish the pending-repair workpiece on the needing-repair part.
2.Configure BD426T special undercoat and brush coating on the pending-repair part,then wait for the primer curing.
3.Configure BD7042 super wear resistant coating and make it be coating on the pending-repair part,knock on it to be compacted
with rubber hammer,then trim the surface with special rounding tools,make the surface be flat and smooth.
4.After initial curing at room temperature,heat it up to the temperature of 100‘ζ slowly and keep this temperature for 2 hours,
cool it down slowly.
5.Coating on the topcoat
Material utilization amount:
35Kg BD7042 slurry pump repair super anti abrasion wear resistant epoxy coatings,1Kg BD426T special undercoat.
Range of application for BD7042 slurry pump anti wear abrasion corrosion resistant repair coating:
Used in the repairing and pre-protecting of slurry pump,cyclone,classifier,jet machine,grit mouth,slurry blender and
the transporting pipe elbow of heavy medium erosive wear under 3mm.
Construction case photos show:
