used in vibrating screen factory vibrating screen beam ceramic rubber lining repairing and protecting
The vibrating screen is widely used in beneficiation and coal washing industry,the equipment has erosive wear and corrosion phenomena
in the process of using,we generally don't repair the screen plate which is a kind of replaceable spare part,but beam and holder as
the basic parts are not easy to change,so we require that it has long-term working life.
There are 3 kinds of protective measures at present:
1.Paste the rubber on the beam and holder(it has falling off phenomena).
2.Cover it with stainless iron sheet(the wear resistance is common).
3.The preparation of integral wear resistant coating with abrasion resistant protective agent.
This factory chooses the wear resistant protective agent from home and abroad many factories to do the small amount test comparison,
finally they choose the BD707 small ceramic beads particle wear abrasion resistant epoxy coatings from Xiangyang City Hundred Shield
Coating Material Co.,Ltd,the wear & corrosion resistance of BD707 anti wear abrasion resistant high alumina ceramic epoxy coating is
excellent,the construction is convenient,the facade doesn't flow.
Construction technology:
1.Polish and clean the beam,holder.
2.Configure BD707 small particle wear resistant coating.
3.Make the adhesives be coating on the pending-protective part uniformly,make the surface be smooth.
4.Curing for 24 hours,when the temperature is below 5‘ζ,should properly heat it up to promote the curing.
Product packaging and actual picture of BD707 wear resistant small ceramic particle coating:
Product construction case photos show:
