ball mill ceramic lining brick repair epoxy adhesives

ball mill ceramic lining brick repair epoxy adhesives
BD200 ball mill ceramic lining brick repair compound epoxy adhesive

Performance features of BD200 ball mill ceramic liner brick repair wear resistant adhesives:
1.It’s made of modified toughening heat resistant resin and special curing agent.
2.Aging resistant,high temperature resistant,with good toughness.
3.The highest working temperature is 200 degree.
4.The viscosity is moderate,easy for construction.

Product usage of BD200 ball mill lining brick bonding repair high alumina ceramic adhesive:
With high bonding strength and good toughness,specially used in the bonding of ball mill liner ceramic lining plate.

How to use:
1.Surface treatment:Clean up the residual lining brick and polish or sand blast on the surface of the cylinder.
Grinding or sand blasting for the new cylinder directly.

2.Configure/Mixing adhesive:Make the A and B double components mix uniformly according to the specified ratio.

3.Using adhesive:Make the mixed-up adhesive be blade coating on the surface of ceramic lining brick uniformly.

4.Curing:It can be put into using after fully curing for 24 hour at room temperature of 25 degree.

Physical performance:
White paste,the shear strength is more than 16Mpa,excellent in aging resistance and temperature resistance.

Performance index:

Density
(g/cm3)
Shear strength
(Mpa)
GB7124-86
Compressive
strength
(Mpa)
G B1041-79
Impact strength
(J/ cm2)
GB6328-86
Limited
temperature resistant
( ‘ζ)
Using quantity
per ton liner plate(Kg)
Usable time
£¨25‘棩
1.35 17 103 34 -60-220 20-25 24

Transportation storage:
1.Sealed for storage in a cool and dry place,the warranty period is 12 months.
2.Avoid placing it upside down,knocking against and transporting it as a non-dangerous product during transportation.

Packaging Specification:

Two components,5Kg/group,packed in a plastic drum.

Product packaging photo of BD200 ball mill ceramic liner brick repairing special adhesives:
