wear resistant ceramic adhesiv > magnetic separator repair anti wear ceramic tile adhesive

magnetic separator repair anti wear ceramic tile adhesive

BD132 magnetic separator repair special wear resistant ceramic tile epoxy compound adhesive

performance features of our BD132 magnetic separator protection anti abrasion ceramic epoxy adhesives:
1.It’s white Two-component adhesive consist of modified toughening resin and composite curing agent)
2.Water resistant, aging resistant,good toughness,shock resistance,fatigue resistance
3.Can cure at the normal temperature, can also heat up for curing)

product usage:
High bonding strength,good toughness,water resistance excellent,with the high bonding strength for the metal-ceramic bonding,it’s exclusively used in the paste of wear resistant ceramic chip on the surface of dry separation,
wet separation and magnetic separator roller

performance index:

product name	physical state	standard packaging	operation time limit (25℃)	usable time (25℃)	range of application
BD132 ceramic tile anti wear epoxy adhesive	sticky paste	5kg	0.5h	6 hours	Used in the self-adhesion and each-adhesion between metal,ceramic and other materials. Especially used in the paste of wear resistant ceramic chip on the surface of dry separation, wet separation and magnetic separator roller

item	color	density (g/cm3)	shear strength (Mpa) GB7124-2008	impact strength (J/cm2) GB6328-1999	tensile strength) (Mpa) GB6329-2008	compressive strength) (Mpa) GB1041-2008	working temperature （℃）
BD132	white	1.34	15	56	84	93	-60-150

How to use:
1.Surface treatment: Grinding or sand blasting to clean up the dust,greasy dirt and rust on the surface of magnetic
separator roller,clean it by cleaning agent in the end.

2.Configure adhesive: According to the specified requirements,make A and B two components mix uniformly A:B=4:1,
when the temperature is low in winter, can separately heat up the A component first to reduce the viscosity for
easy to mix.

3.Using adhesive: Make configured adhesive spread coating on the surface of adherend uniformly,
under the precondition of no shortage of adhesive,scrape the adhesive layers to be the thinner the better.
Coating adhesive for double sides(roller side and ceramic side) will get the best effect.Then make the
ceramic tile paste on the surface of roller and to be compacted.

4.Curing: Initial curing at the room temperature for 4 hours,fully curing for 24 hours （16MPa),heat it up to the
temperature of 80 degree and keep this temperature for 2 hours,then do the last curing,in this way,
it can get the higher combination property(can improve 30%). When the temperature is low in winter,
after the completion of the paste,should keep a certain environment temperature to make the adhesive cure fully
(make the adhesive cure at the temperature above 10 degree as far as possible),
can do irradiation heating with iodine tungsten lamp.

5.Every time the suitable quantity of configuring adhesive is 300g～500g,too much adhesive is not easy to mix uniformly,every time the usable time of configuring adhesive is about 30～40 min,the usable time is long at the low temperature,the usable time is short at the high temperature,
should adjust the configured adhesive quantity according to the actual condition.

Packaging specification:
Packed in a plastic drum, A component: 4Kg/drum, 4 drums/carton; B component: 1Kg/drum, 12 drums/carton or
8 drums/carton.

Transportation storage:
Sealed storage in the cool and dry place. The warranty period is 1 year. Avoid placing it upside down,
knocking against and transporting it as a non-dangerous product during transportation.

Product packaging photo of BD132 magnetic separator roller repair use anti wear corrosion resistant
epoxy ceramic adhesive:
