BD701 pourable anti wear abrasion resistant epoxy coating

BD701 pourable anti wear abrasion resistant epoxy coating

BD701 pourable anti wear abrasion resistant epoxy resin repair compound ceramic coating

Product description:
BD701 pourable anti abrasion wear resistant coating is the high performance wear resistant,corrosion resistant material
which compounded by the highperformance abrasion resistant materials like silicon carbide,first class corundum etc.
And modified toughening resin.Used in the pouring fashioned abrasion resistant workpiece.

Performance features of
our BD701 anti abrasion wear resistant pourable ceramic particle epoxy coatings:
1.Excellent in wear resistance and corrosion resistance
2.The pouring technology is simple,easy for operation.

Product index:

Product item Physical state Operation
time limit
(80‘ζ)
Usable time
(25‘ζ)
Range of application
BD701 pourable anti abrasion
wear resistant coating
Semi-fluid 15min 24 hours Used in the pouring fashioned
abrasion resistant workpiece.

color density
(g/cm3)
Compressive strength
(Mpa)
GB1041-2008
Tensile strength
(Mpa)
GB6329-1999
Shear strength
(Mpa)
GB7124-2009
Bending strength
(Mpa)
GB1042-2008
Working
temperature
£¨‘棩
black 2.6 143 44 13 83 -60‘«120

How to use:
1.Surface treatment: Do coarsening treatment on the pending-repair part,grinding with angle grinder or sand blasting etc,the surface after coarsening treatment should be cleaned,
the surface after this treatment should be the one coarsening,dry and fresh substrates,should be no greasy dirt and dust.

2.Configuration:Heat the A component up to the temperature of about 80 degree,then pour the B component into it
according to the weight ratio 100:5 and mix them uniformly,and use it up within 15 min.Generally while it’s construction
and configuration,every time the largest configuration quantity is not more than 10 kilograms,in order to avoiding partial
adhesive freezing and can’t be used before it hasn’t been used up.

3.Pouring: Make the mixed-uniform BD701 abrasion resistant material pour into the cavity of fashioned molding or
the gap of the workpiece.

4.Curing:it can be put into using after curing for 24 hours at the temperature of 25 degree,or it can be put into using after
curing for 4 hours at the temperature of 80 degree.

Transportation storage:
Sealed storage in the cool and dry place. The warranty period is 12 months. Avoid placing it upside down,
knocking against and transporting it as a non-dangerous product during transportation.

Packaging specification:
25Kg/group,packed in a iron drum.A component: 23.8Kg/drum, B component: 1.2Kg/kettle


Product packaging photo of BD701 pourable high temperature anti corrosion abrasion wear resistant coatings:
